RL1000 Robotic Layer PalletizerNEW

The RL1000 is a high-speed robotic layer forming and palletizing solution. It is well-suited for RSC, wrap-around, lithographic, and display cases and trays, as well as wrapped product. For applications where the use of a vacuum end-of-arm tool is not practical, the RL1000 is the ideal solution because it palletizes full layers of cases without sacrificing speed or case aesthetics. With eight standard layouts, the RL1000 has a configuration to meet each customer’s application and level of automation.

Interact with RL1000

Learn more by interacting with the RL1000 animation.

Features & Specs

  • Palletizes layers of open or sealed cases without sacrificing speed or case aesthetics
  • Activated rollers positioned on pick bed allow for quick transport of layer into position for picking
  • System accumulates additional layer in pick bed resulting in rates of up to 6 layers per minute
  • Layer forming robot end-of-arm tooling from the proven Brenton EOAT library
  • Handles full layers of product up to 600 lbs. and supports the layers from the bottom
